DC Motor

Elegant

PRODUCT SPECIFICATIONS
52
120V / 60Hz,240V / 50Hz
85X28mm
Aluminum
Wood
AGP, BK, WH
6 speeds - Reversible function available
RF Handheld remote controller
18W Dimmable LED light or No light
Made in Taiwan
Product performance

Input Speed Output current (A) Output power (W) RPM CFM
120V / 60Hz
240V / 50Hz
1 0.17 16.1 185 N/A
2 0.15 12.3 165 N/A
3 0.12 9.0 145 N/A
4 0.10 4.9 110 N/A
5 0.09 2.4 70 N/A
6 0.08 2.1 50 N/A

Data above is for reference only, the performance can be set upon request.
